LUMINOUS 1100 VA Shakti Charge Neo 1450 Pro with 36 Months Warranty Square Wave

(0) 0 Reviews 0 Orders 0 Wish listed

₹7,650.00~~₹9,750.00~~

Quantity :

Total price :

(Tax : )

Specifications

Output Features

Efficiency	85 %
Output Voltage	200 – 230 V
Output Frequency	50 Hz ± 2 Hz
Overload	Yes
AC Output Types	Single Phase AC Output
Output Power	924 W
Change Over Time	20 ms
Change Over Voltage	180–260 V (UPS Mode)
VA Rating	1100 VA
Overload Rating	110% for 10 seconds
Other Output Features	Short Circuit & Overheat Protection

Environmental Features

Storage Temperature	-10°C to 55°C
Operating Temperature	0°C to 45°C
Noise Level	<50 dB
Total Harmonic Distortion	<5%
Other Environmental Features	Humidity ≤95% RH (non-condensing)

Warranty

Warranty Summary	36 Months Manufacturer Warranty
Service Type	On-site service by Luminous Authorized Service Center
Covered in Warranty	All electronic components and internal PCB against manufacturing defects
Not Covered in Warranty	Damage due to mishandling, water, physical damage, or installation by unauthorized person
Domestic Warranty	36 Months

Input Features

Input Voltage	90 V – 290 V (ECO Mode) / 180 V – 260 V (UPS Mode)
Input Frequency	50 Hz
Low Cut Input Voltage	90 V
Low Cut Recovery Input Voltage	100 V
High Cut Input Voltage	290 V
High Cut Recovery Input Voltage	280 V
Other Input Features	Wide input range, LVFC tech

Battery Features

Battery Type	Lead Acid / Tubular / SMF
Recharge Time	10–12 hours (at 200 Ah)
Number of Batteries	1
Battery Boost Voltage	14.4 V
Battery Voltage	12 V
Battery Capacity	80–250 Ah supported
Battery Charging Current	20 Amps (Max)
Replacement Battery	Yes
Replacement Battery Type	Tubular/Flat Plate/SMF
Compatible Battery Types	Tall Tubular, Flat Plate, SMF
Compatible Battery Make	Luminous, Exide, Amaron, Livguard
Other Battery Features	Battery Gravity Builder, Smart Battery Management

In The Box

Sales Package

General

Brand	LUMINOUS
Model Number	Shakti Charge Neo 1450 Pro
Battery Included	No
Back Up Time	10 hrs
Load Options	Fans, Lights, Television, PC, Mixer, Set-Top Box, Router
Type	Square Wave Inverter
Model Name	Shakti Charge Neo 1450 Pro
Mode Type	Eco / UPS Mode
Material	Metal with ABS Top Cover
Fixture Type	Floor Mount
Technology Used	Square Wave, LVFC (Low Voltage Fast Charging)
Solar Power Compatible	No
Switch Type	Push Button (Manual Switch between Eco/UPS)
Electrolyte Volume	0 L

Dimensions

Additional Features

Certification	BIS certified
Corrosion Resistant	Yes
Other Features	protect from overload
Key Features	Capacity: 1100 VA / 12V – supports up to 924 Watts load, Compatible Battery: Works with single 12V batteries from 80 Ah to 250 Ah, Fast Charging Even at Low Voltage: Charges batteries even at 95V input using LVFC, Intelligent 32-bit DSP Processor: Ensures efficient power delivery and protection, Backup Time: 6 to 10 hours (depending on battery capacity and usage, Output Type: Square Wave – ideal for fans, lights, TV, PC, mixer, router, and more, Modes: UPS Mode: 180V–260V (for computers & sensitive appliances) Eco Mode: 90V–290V (for energy saving), Overload, Short Circuit & Deep Discharge Protection, Supports High Power Appliances During Cut, Build: Rugged design with digital display and ergonomic indicators

Convenience Features

Emergency Power Off	No
Display Type	LED Indicators
Display Indicator Functions	Mains On, Eco/UPS Mode, Overload, Charging
Audible Indicator Functions	Buzzer for Fault/Overload/Low Battery
USB Charging Port	No
Protection Against	Overload, Short Circuit, Battery Deep Discharge, Reverse Polarity
Cooling System	Air Ventilation, Fan Cooling
Other Convenience Features	MCB protection, Auto reset
