CP PLUS 2.4MP IR Dome Camera - 30Mtr(CP-URC-DC24PL3) Security Camera (N/A TB, 1

(0) 0 Reviews 0 Orders 0 Wish listed

₹793.00

Quantity :

Total price :

(Tax : )

Specifications

Warranty

Power And Connectivity Features

Power Requirement	12 VDC ± 30%
Power Consumption	3 W

General

Sales Package	1 Dome Camera
Model Number	CP-URC-DC24PL3
Number of Channels	1
Camera Type	BNC
Video Output	Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Video Recording Resolution	1080p (1920 × 1080), 960H (960 × 576/ 960 × 480)
Video Recording Frame Rate	CVI: PAL: 1080p@25 fps NTSC: 1080p@30 fps AHD: PAL: 1080p@25 fps NTSC: 1080p@30 fps TVI: PAL: 1080p@25 fps NTSC: 1080p@30 fps CVBS: PAL: 960H NTSC: 960H

Additional Features

Alarm Action	Human Body Detection Support the classification and accurate detection of human & Motor Vehicle
Mobile Compatibility	yes
Application Support	Mobile Software: iCMOB, gCMOB, CMS Software: KVMS Pro Lite
Operating Temperature	–40 °C to +60 °C (–40 °F to +140 °F) degree C
Other Convenience Features	IE, Chrome, Firefox
Material	Plastic
Model Name	2.4MP IR Dome Camera - 30Mtr(CP-URC-DC24PL3)
Color	White
Lens Size	3.6 mm
Angle of View	110 degree
Mounting Type	Wall Mount
Other Features	Storage Humidity <95% (RH), non-condensing

Dimensions

Product Details

Video Formats	H.265+/H.264+/H.264
Recording Formats	Main Stream: All channels 1080N/720P/960H/D1/CIF/(1~25/30fps) Sub stream: CIF (1~15 fps)
Display Frame Rate	25/30fps
Record Modes	Instastream/H.265/H.264+/H.264H/H.264B/ MJPEG (only supported by Sub stream)
Other Video Features	Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Image Sensor	2.4MP PS CMOS Image Sensor
Shutter Type	PAL: 1/25 s–1/100000 s, NTSC: 1/30 s–1/100000 s
Image Resolution	1920 (H) × 1080 (V)
IR Distance	30 m
Number of IR LEDs	2
Other Camera and Imaging Features	Minimum Illumination 0.02 lux@F2.0 (Color, 30 IRE), 0.002 lux@F2.0 (B/W, 30 IRE), 0 lux (IR on), DORI Distance Lens 3.6 mm: Detect-55.0 m, Observe-22.0 m, Recognize - 11.0 m, Identify-5.5 m; Lens 2.8 mm: Detect-44.7 m, Observe-17.9 m, Recognize-8.9 m, Identify-4.5 m
HDD Available	No
Compatible Devices	Monitor
Power Source	DC
Remote Connectivity	Cloud
Remote Pan & Tilt	Pan & Tilt
Storage Type	HDD
USB Port Present	No
Cry Detection Sensor	Yes
Horizontal View Range	30 m
Camera Resolution	2 mp
